Benemed Industry Co., Limited

Features

- Parameters: ECG, SPO2, NIBP, HR, TEMP, RESP
- Networkable with Central Monitoring System
- 720 hours trend data analysis
- Compact design is convenient for mobile monitoring
- Built-in rechargeable battery with Max 6 hour operating time
- Optional: Recorder. Touch screen

Specification

ECG
Connection mode: 5 Leads(R,L,F,N,C or RA,LA,LL,RL,V)
Lead selection: I, II,III ,AVR,AVL,AVF,V
Waveform: 2ch
Lead Mode: 3 Leads (R,L,F or RA,LA,LL)
Lead selection: I, II, III
Waveform: 1ch
Gain: 1/4,1/2,1,2,Auto
HR and Alarm
Range: Adult: 15~300bpm
      Neo/Ped: 15~350bpm
Accuracy: ±1% or ±1bpm, which great
Resolution: 1bpm
Sensitivity: >200(uVp-p)
Differential input impedance:≥5MΩ
ST segment Monitoring Range
Measure and Alarm:-2.0~+2.0mV

Heart rate
Measuring range: 0~350bpm
Accuracy: ±1bpm
Resolution: 1bpm
Sensitivity: >200UVp-p

Respiration
Method: Impedance between R-F(RA-LL)
Differential Input Impedance: >2.5MΩ
Measuring Impedance Range: 0.3~3.0 MΩ
Base line Impedance Range: 200~4000Ω
Bandwidth: 0.1~2.5Hz

NIBP
Method: Oscillometric
Mode: Manual, Auto
Measuring Interval in AUTO Mode: 1, 2, 3, 4, 5, 10, 15,30, 60,90,120,180, 240, 480(Min)
Measuring Period in STAT Mode: 5 Min
Pulse Rate Range: 40~240bpm
Alarm Type: SYS, DIA, MEAN
Resolution
Pressure: 1mmHg
Accuracy: Maximum Mean error: 5mmHg
Maximum Standard deviation: 8mmHg

SPO2
Display: Number of SPO2,waveform of capacity,Pulse
Measuring range: 0~100%
Resolution: 1%
Accuracy: 70~100% (±2%)
Alarm system: Audio-video alarm
Pulse rate range: 0~300bpm

TEMP
Channel: 2
Measuring and Alarm Range: 0~50ºC
Resolution:0.1ºC
Accuracy: 0.1ºC
Actualization interval: about 1 Second.
Average Time Constant: <10 Second.

System
Display system: 12.1 high-brightness color display
Network with central station
Power supply:AC100V~250V,50Hz/60Hz
Printer: Inside Place a printer (The choice install)
Optional Parameter: IBP,EtCO2,Anesthesia Gas,Touch Screen
Size: 300mm×270mm×150mm
Weight: 4kg
