Features:
Throughput: 60T/H 8-inch touch screen
20 parameters + 3 histograms
Sample volume: 10 µL
2 reagents only
3 counting modes
100,000 sample results
Support LIS and external printer
Net weight: 19 kg
CE marked

User-friendly software
Well-organized software allows user to interact with the instrument easily, easy to run QC, sample and check results, etc.

Reliable hardware
Liquid system and circuit board isolation design for less break-down, continous improving hardware to make the instrument more reliable for custoer need

Intelligent design
One press for sample analysis with throughout of 60 sec per test.
High voltage shock and back-flush to remove blockage, auto and manual print is supported

Specification

Principle
Impedance for cell counting
Cyanide-free method for HGB

Parameters
WBC, Neu#, Lym#, Mid#, Neu%,Lym%, Mid%,
RBC, HGB, HCT, MCV, MCH, MCHC,RDW-SD,
RDW-CV, PLT, MPV, PDW, PCT, P-LCR

Histograms
WBC, RBC, PLT histogram

Languages
English, Spanish, Italian, Portuguese, etc.

Calibration
Manual and Auto-calibration

Quality control
3 level QC, LJ graph

Sample volume
Venous mode: 10μL venous blood
Capillary mode: 10μL capillary blood
Prediluted mode: 20μL capillary blood

Display
8-inch color touch screen Liquid Crystal
Display (LCD) Resolution: 800*600

Storage
100,000 sample results with histograms

Reagent
Lyse(500mL) and Diluent(20L)

Print out
Thermal printer, support external printer

Temperature
18ºC-35ºC

Power
AC 100-240V, 50/60 ±1Hz

Dimension
410m m x435mm x472mm
